10 port Fiber Optic Convertor

Description

CVT10-M

The NovaStar CVT-10-M offers a cost-effective method for bridging large distances when transmitting signals.

Features

• 2x 10G optical output (multimode)
• 10x 1G Ethernet port
• 1x USB-B

General specifications:

• Supply voltage: AC 100-240V, 50/60Hz
• Power consumption: 22 watts
• Dimensions: 254.3 x 50.6 x 290 (WxDxH)
• Weight: 2.1 kg

Note:

• •  Optical In / Ethernet Out:
    • If the input device has 8 or 16 LED outputs, the first 8 Ethernet ports of the CVT10-M are available.
    • If the input device has more than 10 or 20 LED outputs, all 10 Ethernet ports of the CVT10-M are available.
    • If Ethernet ports 9 and 10 are not available, they will be available after a future upgrade.
  • Ethernet In / Optical Out:
    • All 10 Ethernet ports of the CVT10-M are available
